Curing Chamber C-2500-N
Standard Function Description:
l Automatic door and three triplock for safty
l 2 tyres backup space for expanding output
l PID system controls temperature, pressure, curing time
l Automatic compensation function on temperature, pressure and time
l Different Pressure control system for Inner Tube, Out Envelope & Curing Chamber
l Three kinds heating for selecting: electric heating, steam heating, oil heating (Standard one is electric heating, if select oil heating, extra add a Conduction Oil Stove)
l Optional Size：4pcs, 6pcs, 8pcs, 10pcs, 12pcs
Technical Parameter:
| Overall： | 7250mm*3000mm *3000mm |
| Effective length： | 4500mm |
| Weight: | 5000kg |
| Rim diameter range： | 25”- 33” |
| Air pressure： | 0.8Mpa |
| Voltage & frequency： | AC 380V/50 HZ (Welcome special demand) |
| Power： | 130.5kw |
| Average curing time： | 3.5 Hours (including air in and air out） |
