·Standard Function
CR segment curing press/vulcanizing machine is used to cure/ vulcanize regular and aircraft tires in
hot retreading.It is designed with segment presses which provide tighter uniformity, allow for more
complex and deeper tread designs, and result in an appearance similarto new tires.Typical industry
mold curing utilizes 6-segment presses or 9-segment presses.
| Main model | CR16 | CR19.5 | CR22.5 | CR385 |
| Curing chamber size(mm) | 940×280 | 990×280 | 1100×360 | 1280×420 |
| Max. tyre diameter(mm) | 900 | 955 | 1060 | 1240 |
| Max. tyre section (mm) | 250 | 250 | 315 | 375 |
| Control air supply (MPa) | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 |
| Steam consumption(Kg/h) | 120 | 120 | 125 | 140 |
| Curing pressure (MPa) | ≤1.8 | ≤1.8 | ≤1.8 | ≤1.8 |
| Power（KW） | 3 | 3 | 3 | 3 |
| Overall dimension(mm) | 2900×2200×1750 | 2800×2700×2100 | 2900×2800×2100 | 3400×3300×2500 |
| Gross weight(ton) | 4.8 | 5 | 5.5 | 7.2 |
| PLC +7’’ touch screen | optional | optional | optional | optional |
| Central bladder system | optional | optional | optional | optional |
